End of Month Garden Brain Dump

So. It’s hot and dry here.

– The salad this year is a lost cause. We’ve gotten three plants from three plantings of lettuces, and the spinach is just beginning to get to edible size.
– We haven’t gotten any chard yet, but the overwintered stuff should be ready for a harvest.
– The overwintered kale has been good for a few meals, but it really wasn’t that impressive for production.
– The carrots planted May 1 or so came up thickly, then disappeared. The parsnips came up and are doing well.
– The peas are just now flowering, the favas are flowering and looking happy.
– The transplanted cauliflower has been in the ground a few weeks, and we’ve only lost two plants. The more recently transplanted brussel sprouts are looking good.
– Onions are looking good, both from the walla walla sets and the seeded guardsman and leeks, then set out as tiny plants.
– There are quite a few potatoes in the carrot bed.
– The potatoes are looking good, the March and April plantings have been hilled at least once, and the May ones are peaking out.
– The reseeding of the beets is working well, we’ve almost got a full bed of them.
– Garlic continues to do well, though I not sure how the seeded garlic will do. It’s still really small.
– The parsely and cilantro have been transplanted ont and are taking to the garden well. Slugs have gotten a couple of parsely, but none of the cilantro.
– I think that the slug beer traps are working. They seem to catch the slugs, and there doesn’t seem to be as much damage now.
– The Strawberries are as happy as I’ve ever seen strawberries in one of my gardens. The transplants from the compost pile are spreading like mad, the ones from the store are putting up huge leaves and lots of berries and flowers. There are a bunch of wild strawberries around the yard, and it almost looks like they’re invasive.
– The peas in the sprawly bed are doing reasonably well. I’m digging small holes there for the squash and sprawly things to grow for a while before I turn the peas in.
– The Pumpkins are in the ground, and looking pretty good. They were started in pots about April 1. I should have started the other squash and cucumbers then.
– The zucchini were started around early May and are good enough to go out, but it would be nicer to have them bigger. The Patty Pan and Butternuts are not ready to go out yet, but might be in a week or so.
– The beans and sunflower seeds have been in the ground a week, and are just starting to sprout. It’s been a warm week.
– There’s at least one apple set that we’ve found, but it’s still hard to see many. I’m expecting more.
– There are lots of cherries, on each tree.
– There’s three plums on one tree, and one on the other. The kids ate 4 plums for snack today. Not going to be enough for a while.
– There’s at least a few peaches on the peach tree, but I’m really worried about it. It has something that looks like a rash or blight, and some of the twigs were hit hard by the weather last winter.
– The pears look happy, but I’m not sure if they’re gong to set fruit. There’s nothing on the asian pear, and one cluster that looks promising on the Bartlett.
– The Blueberries have lots of blossoms and look like they’re setting.
– The Salmon berries are starting to be ripe, and we’ve got a lot of them this year. Knocking down the blackberries did wonders for them.
– The bed is almost ready for the tomatoes and peppers. The tomatoes are ready to go in real soon now, the peppers will probably be a week.
– The Nevada peas are a lost cause, and will get turned in in the next couple of weeks and their place will be taken by corn.
– There’s another planting of Cilantro in the greenhouse, Basil, and some recently repotted Kale. There’s also some extra chard ready for infill in the bed that was planted this spring.

No comments

A couple of Garden Panoramas

Links to the big ones, they’re 3000 and 7000 pixels wide. The originals were more like 10k and 25k wide.

firecircle-pano-md

This one is half a circle, from the beaten down blackberries and resurgent salmonberries, through the fruit trees, fire circle, combined sprawly bed and nevada, now more of a utah shape, and then the raspberries and the blackberries that hide the main garden. This is the big one.

sprawly-pano2-md

The sprawly bed — it’s got favas, garlic strawberries, and peas that are doing anything, a bean trellis in the back, and a few newly planed rows of bush and pole beans. Soon to come are the sprawly things and the sunflowers.

No comments

Yoga Pose

Yoga Pose

No comments

Chainsaw Chair

Chainsaw Chair

Take one at functional chainsaw art. This one is a little tall for Ben.

No comments

Fun with SWIG, wxPython, and the Windows event system

One of the things that I do at the day job is write support for various models of check scanners into our scanning application. It’s a python app, running on Windows using wxPython for the interface. And the one constant in the whole thing is that no two scanners work alike, connect similarly, or have remotely similar APIs. So far, I’ve done:

– Serial
– Serial protocol over Ethernet
– XML over HTTP
– COM Based
– COM Based with Event Callbacks
– SWIGified dll interface
– SWIGified dll interface, with Event Messages

The last scanner that I worked on (which shall go unnamed due to NDA (and really, it’s a published API. Why an NDA? (It’s not like people developing for your scanner wouldn’t like it if everyone copied the same interface))) was the most involved so far, at least to the point of getting the first image out of it. After that, it actually was pretty simple. (And to be fair, there is something called the Ranger API, which does support a good number of scanners, but not all of the ones that we’re interested in. It’s up there, under COM with event callbacks).

Step 1: Getting a SWIG wrapper of the dll to compile using Visual Studio .NET 2003. I’m using VS.net 2003 since I have to stay with what compiled Python 2.4. So, it’s not modern, but it works for what I need it to do. There are a lot of little bits to getting a working SWIG wrapper, especially with debug mode. I gave up on a full debug version of this one due to the difficulty of building a debug version of wxWindows/wxPython on top of all the other python modules that I’d need. First thing is to download SWIG and any other dependencies. I’m on the 1.3 tree of SWIG, later versions may differ. You need to start with a dll project, add the appropriate headers and whatnot. The python libraries and the driver libraries need to be available for linking, the output needs to be put in a \_{module}.pyd file (or
\_{module}\_d.pyd for the debug version). There needs to be a SWIG .i interface file with a custom build step of:

swig.exe -python -o “$(ProjectDir)\$(InputName)_wrap.cxx” “$(InputPath)”

with an output of “$(ProjectDir)\$(InputName)_wrap.cxx”

A minimal .i file for wrapping a windows dll:

%module XVX
%{
/* Includes the header in the wrapper code */
#include “stdafx.h”
#include “XXinterface.h”
%}

/* Parse the header file to generate wrappers */
%include
%include “XXinterface.h”

This .i should swigify and compile, but is not the most useful thing in the world. I had trouble linking, even though all the files to be linked were available. I finally tracked it down to the calling convention — where the last SWIG dll wrapper I made used fastcall, this one required cdecl.

Step 2: Getting a usable hWnd reference from wxPython to a SWIG wrapper so that it worked. The window handle as returned from wxPython’s window.GetHandle() is a python int, which SWIG doesn’t like to automatically convert to a hWnd. So, there’s a little typemap magic in the swig interface file to take that Python integer and turn it into something usable.

/* handle hwnds */
%typemap(in) (HWND Handle) {
$1 = (HWND) ((int)PyInt_AsLong($input));
}

It’s a little ganky in that I’m taking a random integer and making it a window handle, but looking at all the typedefs, I’m pretty sure that it’s a valid approach. What I’m not 100% sure of is if this will work on 64bit machines. I reserve the right to revisit this when I have a 64bit test machine with dev tools.

Step 3: Hooking the Event system so that we could catch ON_MESSAGE events.
The sample code I have is for a MFC C++ app, and it has a message map:

BEGIN_MESSAGE_MAP()
ON_MESSAGE(CUSTOM_EVENT,myHandler),

END_MESSAGE_MAP()

It turns out that while wxWindows/wxPython does get most events (mouse, command, menu, etc) and allow them to be handled by registering a handler, the ON_MESSAGE event is not one of them. The messages come into the application through a WndProc. The only reference I found in google for this was a faq page which references a MSWWindowProc that you have to override. That didn’t appear to work, which led to this list message (which is archived at a few places on the web, but on devshed.com, it doesn’t have the all important link to the answer) that links to code for overriding the WndProc and getting all the messages that you need. Once you have that, it’s a simple matter of filtering for the message type sent by the driver.

Step 4: Fleshing out the SWIG interface so that it’s not quite as painful to use. There are a lot of methods that pass back short strings in a buffer that you provide. That’s easily handled using a typemap pair in the .i file. This fragment will take the char* outString, BYTE MaxLen pair, wherever they appear, and drop them from the required python arguments of the function, and append them to the result. It could be a bit better, in that it returns all 255 characters from the buffer and it returns an array of [boolean, string] to python. I’m still working on a fix for that.

/* handle the strings */
%typemap(in,numinputs=0) (char* outString, BYTE MaxLen)(char s[255]) {
$1 = s;
$2 = 255;
}
%typemap(argout) (char* outString, BYTE MaxLen){
$result = SWIG_Python_AppendOutput($result, SWIG_FromCharPtrAndSize($1,$2));
}

I tend to target named parameters, rather than target any type combination like char*, BYTE. It’s easy enough to apply this to other names:

%apply (char* outString, BYTE MaxLen) { (char* ErrorString, BYTE MaxLen) };

Next, the ON_MESSAGE event has two parameters, a message and one that’s either a pointer or an int. Since that pointer is delivered directly to python without being able to typemap it to something else, I’ve added a couple of convenience methods for getting the contents of that pointer. (without pulling ctypes into it) The typemap does something similar to the hWnd typemap above, and the inline function just returns my input, but SWIG will take that pointer and turn it into the python representation of that structure.

%typemap(in) (ImagesStruct *pImageStruct) {
$1 = (ImagesStruct *) PyInt_AsLong($input);
}

%inline %{
ImagesStruct * WINAPI _GetImageStruct(ImagesStruct *pImageStruct ) {
return pImageStruct;
}
%}

No comments
